Monday, January 24, 2011

Cage done & send bottom end to Machine Shop

Roll Cage final Coat and Interior


Sending the Bottom end to the Machine Shop
crank shaft to be knife-edged, bored to 85.5mm from 84mm, balanced drive shaft, and pre-assembled...


Friday, January 21, 2011

Roll Cage n Engine Head

Rollcage primed and 1st coat
im getting impatient as the work progress getting slower... but i had no other choice but wait.... Sad well... now its primed and 1st coat....




Engine head work progress
bought more parts (gasket kit) as the head work is almost complete


Thursday, January 20, 2011

Ottosan Update :)

Leaking Clutch Pressure Hose
so my guess was right, the clutch pressure hose has hair line crack... thus losing pressure.... replaced it


Replaced New Brake Disc and bleed the brake
was surprised that this merc use brembo as it's OEM Disc Brake....


Rubber Spring Seat
just found out that the merc has different height rubber spring seat. i was on '1 dot' at the front (the lowest) and '3 dot' on the back (the highest)... so i replaced the back to the '1 dot' and the front to the '2 dot'....
now its more leveled than before


BEFORE (was rubbing at the front on hard corner)


AFTER




Tuesday, January 18, 2011

my new pajama


SHIROSAME [白鮫]

Some folk story from indonesia...

Few cars and the drivers have been missing whilst racing around Hilir Dam (Bendungan Hilir). the Dam water came from the verocious river called Riverside.

The Locals believed that there is one Freshwater White Shark lurking in the Riverside... called Shirosame (read: see-row-sa-mae. 白鮫) which rumor has it that Shirosame has rusty Metal skin, scale and bones, with 6 hearts and only swim using its rear rubber fins. This Shark has never been seen, but again the rumor has it that the amount of pollution, junk and rubbish in the river has made the Shirosame mutated into amphibians Shark and capable of roaming outside the water...

So last night i dreamt about this mighty Shark and try to recreate the image of Shirosame... i came up with few results... i am pretty sure it would most probably look like the top 2, but who knows??








sorry for the bu!!sh!t Very Happy

Sunday, January 16, 2011

Day 11, 12 & 13 @ Riverside

Day 11 at RIVERSIDE
work done by: Riverside. Race/Rally Preparation, Engine rebuild and Competitive Parts.
http://www.riversiderallyteam.com/

the main loop is in and aligned. waiting for the rear half bars


Day 12 at RIVERSIDE
Rear half bars is in, with the harness bar and rear strut bar.


reassemble front suspension


Day 13 at RIVERSIDE
Roll 6 point full cage is done, waiting for the painting

main loop base


rear strut bar


front overhead cross bar



rear bars


door cross bars

Muffler's Neck Broken

Muffler's Neck Broken Sad
the micra suddenly sounds like fart and i can hear loud metal knocking sound every corner...

turned out that the muffler broke around the nexk due to rust around the welding area, and the pipe fell off and hitting the rear axle...

so i drove to Unique exhaust and got a replacement one for $80(installed) straight thru muffler, replacing the old offset muffler...
